Specifications:
Product: MPG Handwheel
Model: MPG 60
Input voltage: 5V
Pulse: 100PPR
Introducing the MPG60 Handwheel
In CNC machines, accuracy in controlling the moving axes and adjusting the tool position is of great importance. One of the key tools for achieving this accuracy is the handwheel, which allows the operator to manually and accurately control the machine axes. The MPG60 handwheel is one of the most widely used and high-quality models in this field, designed to be installed on the main panel of the machine and is used in many numerical control systems due to its robust structure, smooth operation and high accuracy. With a compact design and a diameter of 60 mm, this product is easily installed on the machine panel and allows the operator to manually control various axes.
Technical and functional features of the MPG60 handwheel
The MPG60 handwheel with a 5 V power supply and 100 pulse output provides accurate and stable performance. The high precision of this device allows the operator to perform X, Y and Z axis movements in millimeters and with ultimate control. The internal structure of the handwheel consists of precise pulse-generating sensors that generate a certain amount of digital signals with each rotation. These signals are interpreted by the device controller and converted into precise axis movement.
The industrial design of the body, high build quality and the use of durable components have made the MPG60 handwheel highly resistant to shock, vibration and temperature changes. These features make it an ideal option for use in harsh industrial environments and CNC machines with continuous operation.
Design and build quality
The MPG60 handwheel, with its compact design and precise construction, is made of durable alloys and high-quality electronic components. Its 60 mm diameter allows the operator to have complete control when adjusting the axis or manually moving the workpiece. The rotating surface of this model also has standard friction to give the user a greater sense of control when rotating.
In addition to the high mechanical quality, the electrical connections of this handwheel are designed with high precision so that signals are transmitted to the machine controller without loss or noise. This precision in design has made the MPG60 handwheel suitable for use in new generation CNC systems and even older models.
Panel Handwheel Function in CNC Systems
Panel handwheels are mounted directly on the control panel of the machine and are usually used to manually adjust the position of the tool or machine axes. These types of handwheels are more stable than portable or cordless models and are more efficient in operations that require frequent precise adjustments. The MPG60 handwheel transmits axis movement information to the controller with high accuracy by generating precise pulse signals. As a result, the operator can control very fine and precise movements when adjusting the machine or performing sensitive machining processes.
The importance of using handwheels in CNC machines
In machining processes, adjusting the position of the tool before starting work or after the operation is very important. Any error at this stage can lead to damage to the workpiece or tool. For this reason, using a handwheel allows the operator to achieve the necessary positioning accuracy by manually and stepwise moving the machine axes. The MPG60 handwheel makes this process simpler and safer with its fast response and precise signals.
Compatibility with systems and other controllers
The MPG60 handwheel is fully compatible with numerical control systems and can be used in a variety of CNC machines based on this brand. This model is also compatible with other similar controllers in many cases. Its standard electrical design and 5V voltage make it usable in various industrial systems and can be connected to the control circuit without the need for special hardware changes.
Industrial Applications
The MPG60 handwheel is used in a variety of industrial machines, including CNC lathes, CNC milling machines, laser cutting, plasma and EDM. This product allows the operator to manually check and adjust the axis movements before executing automatic programs. In precision operations such as molding or turning sensitive parts, using this type of handwheel reduces errors and increases user control over the process.
Advantages of using the MPG60 handwheel
The MPG60 handwheel with high accuracy, robust design and fast response is one of the best options for manual control of CNC machines. This device with a low voltage of 5 volts and an output of 100 pulses per revolution, in addition to low energy consumption, has very precise performance. Easy installation on the panel, long life, noise resistance and standard design are other important advantages. Operators feel complete control over the machine when using this handwheel, which significantly increases the productivity and quality of operations.
