Specifications:
- Product: Cooling Fan
- Brand: Commonwealth
- Model: FP-108EX-S1-B
- Type: AC Industrial Axial Fan
- Dimensions: 172 x 152 x 50 mm (oval frame)
- Operating Voltage: 220V/240V AC (range 185 to 245 volts)
- Frequency: 50/60 Hz
- Current Consumption: 0.22 to 0.29 Amps
- Power Consumption: 35 to 38 Watts
- Rotation Speed: 2700 to 3100 RPM
- Air Flow: Approximately 190 to 235 CFM (Cubic Feet per Minute)
- Bearing System: Dual Ball Bearing with Long Life
- Body material: Die-cast aluminum with anti-corrosion black paint
- Improvement material: Fiberglass reinforced plastic (flame retardant UL 94V-0)
- Protection system: Impedance Protected
- Connection type: 2 output wires (length about 25 cm)
- Noise level: 50 to 60 dB (depending on speed and frequency)
- Life span: 50,000 hours (at 40 ° C)
- Operating temperature: -20 to +75 ° C
Description of the axial fan
The Commonwealth FP-108EX-S1-B fan is an AC industrial axial fan with dimensions of 17.2 * 15.2 * 5 cm, with double ball bearings.
This fan operates at a voltage of 220-240 V AC and at frequencies of 50/60 Hz. Its current consumption is usually between 0.22 and 0.29 A, which results in a power consumption of 35 to 38 W.
This model usually reaches a speed of 2800 revolutions per minute (RPM) and creates an air flow equivalent to 5.1 cubic meters per minute (about 180 CFM). Its noise level is about 58 dB.
This fan has a ball bearing for long life and reliable performance. Its body is made of die-cast aluminum alloy and its blades are made of plastic and are connected via 2 strands of wire.
This fan is widely used for general cooling in electrical panels, industrial equipment and various electronic systems.
