Introducing the EFB0512HA CPU Cooling Fan
The EFB0512HA CPU cooling fan is one of the important components in maintaining the performance and health of processors. This fan is offered with high cooling capacity and a suitable design for industrial, electronic and computer applications. The technical features of this fan have made it used in many computer and electronic systems that require high heat dissipation.
Applications of the EFB0512HA CPU Cooling Fan
The EFB0512HA CPU cooling fan is used not only in computers, but also in a variety of electronic systems, CNC equipment, control circuits and precision instruments. With its small but powerful design, this fan is a reliable choice for local cooling in limited spaces. Easy installation, reasonable noise and low energy consumption are the main advantages of this product.
Review of the dimensions of the EFB0512HA CPU cooling fan
The dimensions of this fan are 10×50×50 mm, which indicates its compact and efficient design. Such dimensions allow it to be easily placed in tight spaces, without creating an obstacle for other components. These standard dimensions have made the EFB0512HA a popular choice for specific and limited applications.
Precise operation at 12V DC
The EFB0512HA CPU cooling fan operates at 12V DC. This feature makes it suitable for use in most computer and industrial systems that are powered by 12V. Operating at low voltage reduces energy consumption and increases operational safety, especially in sensitive environments such as medical or industrial devices.
Efficient consumption with 0.15A current and 1.2W power
Other technical features of this product include a current consumption of 0.15A and a power consumption of 1.2W. These numbers indicate the high efficiency of the fan in converting energy into air flow. In other words, the EFB0512HA can provide effective cooling performance with low energy consumption, which is important for systems with energy constraints.
Rotation speed and air flow production
The rotation speed of the EFB0512HA CPU cooling fan is 5500 revolutions per minute (RPM). This high speed, along with the precise design of the fan blades, helps produce an airflow of 11.40 CFM, which is equivalent to 0.323 cubic meters per minute. This airflow rate is quite sufficient and effective for cooling processors or sensitive electronic components.
Performance sound and noise level
One of the concerns of users when choosing a fan is the noise level it produces. With a noise level of 30.0 decibels, the EFB0512HA fan has a relatively quiet operation, making it suitable for use in office, home or small spaces. Less noise means more comfort for users while working with the device and will not cause any disturbance in 24-hour applications.
Static Pressure and Performance in Limited Conditions
The static pressure of this fan is 0.167 inches of water (or 4.24 mm of water). High static pressure in fans means a high ability to move air against environmental resistances such as filters, heatsinks, or narrow ducts. This feature allows the EFB0512HA fan to perform its task properly even in special conditions.
Using a three-wire system for better control
The EFB0512HA CPU cooling fan is a three-wire type that includes a power wire, a ground wire, and a signal wire (for speed control or receiving feedback from the fan). This feature allows you to monitor the fan’s performance and is widely used in systems that require precise thermal control.
High build quality and durability
This fan is made of high-quality materials and is designed to ensure a long service life. Precise and durable bearings, a protective shell against dust and moisture, and stable operation at different voltages are the prominent features of this model. These features make the EFB0512HA fan a reliable choice for projects that require stability and durability.
Buy CPU Cooling Fan Model EFB0512HA from 24CNC
If you are looking for a cooling fan with compact dimensions, low energy consumption and high performance, the CPU Cooling Fan Model EFB0512HA is a very suitable option. 24CNC store offers this product with a guarantee of quality and authenticity. You can purchase this fan at the best price and technical support from 24CNC site and use it in your system with peace of mind.
